1套具有上下功能的气缸和仅具有退料机功能的4套气缸的结构，用于重物推料机的促动器

发挥普通气缸的5倍推力（提升时）

适于组装机传送生产线的推料机及塞子、压力部件

可安装位置检测磁性开关

■ Actuator consists of 1 Up Down Air Cylinder and 4
Lifter Air Cylinders
■ 5 times thrust than general cylinder (in lifting)
■ Applicable to lifter, stopper, and press for the
assembly and return line
■ Auto Switch for the detection of position can be
attached
