以输出轴为中心，通过链将2套活塞连接起来，组合空气和油的特点，转换为旋转式运动的摇动型旋转缸
基于水电检查原理，低速区下也可顺畅旋转式
发生轻微漏油时，也可通过内置的止回阀将旋转式部分后的冲击最小化
高负荷、高强度型结构可应对高力矩
旋转式部分标配外部塞子，可实现高精度的位置确定
输出轴为中空形式，可与其他设备组合及进行配线配管处理
可安装角度检测磁性开关
适于构成FA组装及传送生产线的翻转作业用贴装系统
■ Rotary Cylinder, which converts motion to combined
rotary motion along with the characteristics of air and
oil by connecting 2 pistons with chain and centering
output shaft.
■ Smooth rotation even in low-speed with hydro check
■ Even in fine oil leakage, eliminated back lash in
rotation unit by built-in check valve
■ Handling high movement with high load and highsolidity
type structure
■ Equipped with external stopper tool that allows
rotation unit to perform high-accuracy positioning
■ Wiring and piping enabled with hollow output shaft
combined with other devices
■ Auto Switch for the detection of position can be
attached
